MARINE PLYWOOD (IS: 710)
KDC Marine plywood is a specially treated plywood that is designed to resist rotting in a high-moisture environment. Marine plywood is frequently used in the construction of docks, boats and other marine vessels.
Certified by the Bureau of Indian Standards, DURATECH Marine plywood surpasses the required standards. It is manufactured with utmost care and the supervision of technical experts with well selected pieces of core and face veneers. High Density Durjan Wood with superior phenol bonded resins are used to manufacture Marine Plywood. DURATECH Marine Ply resists all types of climatic conditions. Marine plywood is stronger and has consistent mechanical Properties.
Advantage
- Borer proof & termite proof
Application
- Cabinets in Kitchen and Bathroom
- Ship/Bus Body Building
- Paneling/Partitions/Ceiling/Wardrobes/Counters
Available in
- Thickness - 4 mm / 6 mm / 8 mm / 12 mm / 15 mm / 19 mm
| Test | Technical Details | Results |
|---|---|---|
| Moisture Content | - | 5% To 10% |
| Glue Sheer Strength (Dry State) | - | More than 1350 N |
| Adhesion of plies | - | Excellent |
| Water Resistant test | Water for 3 hours |
a) Indv. Min - 784.5 (confirms to specified requirements) b) Average - 980.7 (confirms to specified requirements) |
| Glue Shear Strength | - | Excellent |
| Adhesion of plies | - | Excellent |
| Tensile Strength | - |
a) Parallel to grain - more than 450 kg/cm2 b) Right angle to grain - more than 250 kg/cm2 |
| Mycological Test | - |
a) No Separation at edges after 21 days of exposure to micro organism b) Shear strength more than 1000 N |
| Specific Gravity | - | 0.70 to 0.75 |
| Water Absorption | - | - |
| Screw holding strength | - | more than 250 kgs. |
| Nail Holding strength | more than | 250 kgs. |
